• Class I equipment with reinforced insulation: IMY models
• Programmable input undervoltage lockout
• Shutdown / inhibit input
• Adjustable output voltages with flexible load distribution
• External frequency synchronization
• Output no-load, overload, and short-circuit proof

Article number	110IMY70-12-0TG
Available stock	2
Manufacturer	Bel Power
Type	DC/DC
Input Voltage	43.2 – 154VDC
Output voltage	12V
Output current	7.5A
Total power	90W
Op. temperature	-40 / +95°C
Size	76.2×63.5×12.5mm
Weight	140g
Efficiency	91%
Formfactor	THT mountable
Application	Industry
Specials	EN60950, current share

The IMX/IMY70 Series of board-mountable 70 Watt DC-DC converters has been designed according to the latest industry requirements and standards. The converters are particularly suitable for use in mobile or stationary applications in transport, railways, industry, or telecommunication, where variable input voltages or high transient voltages are prevalent.
Covering 24, 72, 96 & 110 V battery voltages with 2 different models, the converters are available with one or two electrically isolated outputs from 5 V to 48 V, externally adjustable and with flexible load distribution. A shutdown input allows remote converter on/off. Features include consistently high efficiency over the entire input voltage range, high reliability, and excellent dynamic response to load and line changes
