• Class I equipment
• Input over- and undervoltage lockout
• Outputs: ES1, no load, overload, short-circuit proof, rectangular current limiting characteristic
• Adjustable output voltages with remote on/off
• Emissions according to EN 55011/55032

Article number	DM3578-5
Available stock	2
Manufacturer	Bel Power (Melcher)
Type	DC/DC
Input Voltage	44 – 220VDC
Output voltage	15V
Output current	3A
Output voltage 2	15V
Output current 2	1.1A
Output voltage 3	5.1V
Output current 3	1.5A
Total power	70W
Op. temperature	-25 / +71°C
Size	169×38.7x111mm
Weight	770g
Efficiency	77%
Formfactor	Casette
Application	Railway
Specials	EN 50155, EN 50121

The M Series of DC-DC and AC-DC converters represents a broad and flexible range of power supplies for use in advanced industrial electronic systems. Features include high efficiency, reliability, low output voltage noise and excellent dynamic response to load/line changes due to individual regulation of each output.
The converter inputs are protected against surges and transients occurring at the source lines. An input over- and undervoltage lockout circuit disables the outputs, if the input voltage is outside the specified range. An inrush current limitation prevents circuit breakers and fuses from tripping at switch-on.
All outputs are open- and short-circuit proof, and are protected against overvoltages by means of built-in suppressor diodes. The outputs can be inhibited by a logic signal applied to the connector (pin 2). If the inhibit function is not used, pin 2 should be connected to pin 23 to enable the outputs.
LED indicators display the status of the converter and allow visual monitoring of the system at any time.
Full input to output, input to case, output to case, and output to output isolation is provided.
The case design allows operation at nominal load up to 71 °C in a free-air ambient temperature. If forced cooling is provided, the ambient temperature may exceed 71 °C but the case temperature should remain below 95 °C under all conditions.
A temperature sensor generates an inhibit signal, which disables the outputs, when the case temperature TC exceeds the limit. The outputs automatically recover, when the temperature drops below the limit.
