- Industry standard pinout
- 2kVDC/1s isolation
- UL94 V-0 package material
- Fully encapsulated
| Article number | RO-1212S/H |
| Available stock | 1 |
| Manufacturer | Recom |
| Type | DC/DC |
| Input Voltage | 10.8 – 13.2VDC |
| Output voltage | 12V |
| Output current | 83mA |
| Total power | 1W |
| Op. temperature | -40 / +85°C |
| Size | 11.5x6x10mm |
| Weight | 1.4g |
| Efficiency | 82% |
| Formfactor | THT mountable |
| Application | Industry |
| Specials | 1kVDC isolation, fully encapsulated |
The RO DC/DC converters are typically used in general purpose power isolation and voltage matching applications, and feature a full industrial operating temperature range of -40°C to +85°C without derating.
