- 1kVDC isolation
- UL94V-0 package material
- Continuous short circuit protection
- Low ripple and noise
- CTRL On/Off
| Article number | RS3-2405DZ |
| Available stock | 10 |
| Manufacturer | Recom |
| Type | DC/DC |
| Input Voltage | 9 – 27VDC |
| Output voltage | 5V |
| Output current | 300mA |
| Output voltage 2 | -5V |
| Output current 2 | 300mA |
| Total power | 3W |
| Op. temperature | -40 / 71°C |
| Size | 21.8×9.2×11.1mm |
| Weight | 4.7g |
| Efficiency | 77% |
| Formfactor | THT mountable |
| Application | Industry |
| Specials | EN60950, 1kVDC isolation, SCP |
Very high power density, 2:1 or 3:1 input voltage range and a wide operating temperature range -40°C to +71°C and extra features such as On/Off control are just some of the characteristics of this converter which is ideal for highly sophisticated industrial designs.
