- 3kVDC isolation
- SMD package style
- Continuous short circuit protected
- Low ripple and noise
- IEC/EN60950-1 certified
| Article number | RW2-4815S/H3/SMD |
| Manufacturer | Recom |
| Type | DC/DC |
| Input Voltage | 36 – 72VDC |
| Output voltage | 15V |
| Output current | 134mA |
| Total power | 2W |
| Op. temperature | -40 / +85°C |
| Size | 24.2×14.5×10.2mm |
| Weight | 6.4g |
| Efficiency | 83% |
| Formfactor | SMT mountable |
| Application | Industry |
| Specials | 3kVDC isolation, EN60950, EN55032 |
High power-density, 2:1 input voltage range and a wide temperature range of -40°C to +85°C are just some of the characteristics of this versatile DIP16 converter, ideal for highly sophisticated industrial designs where a regulated converter is required but space is at a premium.
